FANUC Series 16i/18i/21i-TA/TB Additional Manual Page 17

Additional Manual
A-76286E
Sheet
Title
Draw
No.
16 Apr.19.'04 Addition or Modification of 16)
15 Jul.02.'02 Y.Takeuchi Improvement of status display T.Endo
14 Jun.21.'02 Y.Takeuchi Improvement of status display T.Endo
13 May.27.'02 Y.Takeuchi Addition of status display and improvement of S/T code output T.Endo
12 Mar.18.'02 Y.Takeuchi Availability of direction change movement in auxiliary function T.Endo
11 Jan.22.'02 Y.Takeuchi Availability of Angular axis control and Advanced preview control T.Endo
10 Oct.03.'01 Y.Takeuchi Addition or Modification of "5. About function improvement" T.Endo
Ed.. Date Design Description
Date May.02.’97 Desig. K.Ishida Apprv. T.Nakazato
FANUC Series 16i/18i/21i-TB/TB
Manual Handle Retrace
Specifications
17/40
3.2 DI / DO
3.2.1 DI signal
G0067
MCHK MMOD MRVM
MRVM Reverse movement prohibition signal
0: In checking mode, the reverse movement is permitted.
1: In checking mode, the reverse movement is prohibited.
MMOD Checking mode signal
0: Checking mode is not available.
1: If the mode is MEM, checking mode is available.
MCHK Handle available signal in checking mode
0: In checking mode, the operation is equal to the automatic operation.
1: In checking mode, the operation, which is synchronized with the manual handle,
is executed.
.
3.2.2 DO signal
F0091
MRVSP MNCHG MRVMD
MRVMD Reverse movement signal
0: The operation is forward movement.
1: The operation is reverse movement.
MNCHG Direction change prohibition signal
0: Changing forward and reverse movement is available.
1: Changing forward and reverse movement is prohibited.
MRVSP Reverse movement prohibition signal
0: Reverse movement is available.
1: Reverse movement is not available.
4. Notes
1) This function is an option function and available on only T-series.
The following option besides this function option is needed.
• Manual handle feed
2) This function cannot coexist with the following functions
• Advanced preview control
• Angular axis control
• Arbitrary angular axis control
• Canned grinding cycle
10)
10)
10)
10)
