FANUC SERIES 0/00/0-MATE Operators manual Page 427

Operators manual
OPERATION
B–61404E/08
2. OPERATIONAL DEVICES
404
Before an external input/output device can be used, parameters must be
set as follows.
Series 0
MEMORY CARD
Channel 1
Channel 2 Channel 3
M5
M74
RS–422RS–232–CRS–232–C
M77
RS–232–C
Reader/
puncher
Host
computer
Host
computer
Reader/
puncher
I/O = 0
or
I/O = 1
I/O = 2
I/O = 3 I/O = 3
REMOTE BUFFER
Series 0 has three channels of reader/punch interfaces. The input/output
device to be used is specified by setting the channel connected to that
device in setting parameter I/O.
The specified data, such as a baud rate and the number of stop bits, of an
input/output device connected to a specific channel must be set in
parameters for that channel in advance.
For channel 1, two combinations of parameters to specify the input/output
device data are provided.
The following shows the interrelation between the reader/punch interface
parameters for the channels.
I/O
Specify a channel for an
input/output device.
I/O
= 0 : Channel 1
= 1 : Channel 1
= 2 : Channel 2
= 3 : Channel 3
I/O = 0
(channel 1)
002
Stop bit and other data
038 #6,#7
Number specified for the
input/output device
552
Baud rate
I/O = 1
(channel1 )
012 Stop bit and other data
038 #6,#7
Number specified for the
input/output device
553
Baud rate
I/O = 2
(channel 2)
050
038 #4,#5
250
I/O = 3
(channel 3)
051
038 #1,#2
251
055#2
Selection of protocol
055 #3
Selection of RS–422 or
RS–232C, and other data
Parameter Number
Stop bit and other data
Number specified for the
input/output device
Baud rate
Stop bit and other data
Number specified for the
input/output device
Baud rate
SETTING
