Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 156

Maintenance manual

Page of 907

/ 907

B--63005EN/02

1. DISPLAY AND OPERATION

131

Using the periodic maintenance screens makes it easy to manage

consumables (such as LCD unit backlight and backup battery) that are to

be replaced periodically.

Setting the name and service life of consumables, and the countdown

method to be used for them enables counting of theremaining servicetime

according to the specified countdown method and displaying of the result.

The following periodic maintenance screens are available:

(1) Status screen: Displays item names, remaining service time,

countdown status, and lets you specify item names.

(2) Setting screen: Lets you specify service life, remaining service time,

and count type (countdown method).

(3) Machine system menu screen: Enables registering the names of

consumables used in the machine.

(4) NC system menu screen: Displays the names of registered

consumables used in the NC.

To use this function, follow the steps below:

(1) Select a number for registration (using the cursor key on the status

screen).

(2) Specify an item name.

The following two methods are available.

-- Selecting a name from a menu screen (machine or NC system menu

screen).

-- Entering a name to the status screen directly from the MDI.

Using the machine system menu screen requires that item names be

registered previously.

(3) Specify the service life, remaining service time, and count type for a

target item.

Once they are specified, the remaining service time can be checked

on the status screen.

1Pressthe

SYSTEM

function key.

2Pressthe

continuous menu key several times. Soft key

[MAINTE] appears.

3 Press soft key [MAINTE]. A periodic maintenance screen appears.

There are two periodic maintenance screens, status and setting screens.

Either screen can be selected using soft key [CHANGE].

1.19

PERIODIC

MAINTENANCE

SCREENS

1.19.1

Overview

D Screen configuration

D Procedure

1.19.2

Screen Display and

Setting
