Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 807

Maintenance manual

Page of 907

/ 907

B--63005EN/02

G. FSSB START--UP PROCEDURE/

MATERIALS

APPENDIX

783

When the following parameters are set, automatic setting can be

performed using the FSSB setting screen:

Bit 0 of No. 1902 = 0

Bit 1 of No. 1902 = 0

For automatic setting on the FSSB setting screen, use the procedure

below.

1 Set a servo axis number in No. 1023.

Be sure to match an axis number set in No. 1023 with the total number

of axes of the servo amplifiers connected via optical cables.

2 On the servo initialization screen, initialize the servo parameters.

3 Turn off then on the power to the CNC.

4 Press function key

SYSTEM

5 Pressing the continuous menu key

several times displays

[FSSB].

6 Pressing soft key [FSSB] switches the screen display to the amplifier

setting screen (or the FSSB setting screen selected previously), and

displays the following soft keys:

[][][][][]

7 Press soft key [AMP].

8 On the amplifier setting screen, set a controlled axis number connected

to each amplifier.

The amplifier setting screen lists the slaves in ascending order of slave

numbers from top to bottom. So, when setting controlled axis

numbers, consider which amplifier axis is to be connected to which

CNC axis, sequentially, starting with the amplifier axis closest to the

NC. On this setting screen, 0 andduplicate numberscannot be entered.

No. AMP SERIES UNIT CUR. [AXIS] NAME

1 A1-L ∼ SVM 40AL [ 1 ] X

2 A1-M ∼ SVM 12A [ 2 ] Y

3 A2-L ϒ SVU 20A [ 3 ] Z

4 A3-L ∼ SVM 40A [ 4 ] A

5 A3-M ∼ SVM 80A [ 5 ] B

7 A4-L ∼ SVM 40AS [ 6 ] C

NO. EXTRA PCB ID

6 M1 A 0008 DETECTOR(4AXES)

8 M2 A 0008 DETECTOR(4AXES)

MDI **** *** *** 13:11:56

[ AMP ][ AXIS ][ MAINT ][ ][ (OPRT) ]

9 Press soft key [SETING]. (This soft key appears when a value is

entered.)

10 Press function key

SYSTEM

G.3

AUTOMATIC

SETTING
