Series 16i/18i/20i/21i/160i/180i/210i/160is/180is/210is - Model A Maintenance manual Page 837

Maintenance manual

Page of 907

/ 907

B--63005EN/02

G. FSSB START--UP PROCEDURE/

MATERIALS

APPENDIX

813

D AXIS NO: Controlled axis number

The controlled axis numbers set in parameter Nos. 1920 through 1929

are displayed.

When a value outside the range 1 to the maximum number of

controlled axes is set, 0 is displayed.

D NAME: Controlled axis name

The axis name set in the parameter No. 1020 corresponding to a

controlled axis number is displayed. When the controlled axis number

is 0, -- is displayed.

D As amplifier information, the following information items are

displayed:

S UNIT: Type of servo amplifier unit

S SERIES: Servo amplifier series

S CURRENT: Maximum current value

D As pulse module information, the information items below are

displayed.

S EXTRA

The character M, which stands for “pulse module,” is followed by

the ordinal number of a pulse module counted from the pulse

module closest to the CNC.

S TYPE

The type of a pulse module is displayed by a letter.

S PCB ID

The ID of a pulse module is displayed using four digits in

hexadecimal. For a separate detector module (8 axes),

DETECTOR (8AXES) is displayed after the pulse module ID. For

a separate detector module (4 axes), DETECTOR (4AXES) is

displayed after the pulse module ID.

The axis setting screen displays axis information.

(AXIS SETTING) O1000 N00001

M1 M2 Cs

1 X A1-L 0 00 01

2 Y A1-M 1 0 1 0 0

3 Z A2-L 0 0 0 1 0

4 A A3-L 0 0 0 0 2

5 B A3-M 0 0 0 0 0

6 C A4-L 0 0 0 0 0

MDI **** *** *** 13:11:56

[ AMP ][ AXIS ][ MAINT ][ ][ (OPRT) ]

The axis setting screen displays the items below.

G.9.2

Axis Setting Screen
