Series 0i - Model A Parameter manual Page 16

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63510EN/01
10
#7
0002
#6 #5 #4 #3 #2 #1 #0
SJZ
Setting entry is acceptable.
[Data type] Bit
SJZ Manual reference position si performed as follows:
0 : When no reference position has been set, reference position return is
performed using deceleration dogs. When a reference position is
already set, reference position return is performed using rapid traverse
and deceleration dogs are ignored.
1 : Reference position return is performed using deceleration dogs at all
times.
NOTE
SJZ is enabled when bit 3 (HJZ) of parameter No.1005 is
set to 1. When a reference position is set without a dog,
(i.e. when bit 1 (DLZ) of parameter No.1002 is set to 1 or
bit 1 (DLZx) of parameter No.1005 is set to 1) reference
position return after reference position setting is
performed using rapid traverse at all times, regardless of
the setting of SJZ.
#7
0012
#6 #5 #4 #3 #2 #1 #0
MIRx
Setting entry is acceptable.
[Data type] Bit axis
MIRx Mirror image for each axis
0 : Mirror image is off.
1 : Mirror image is on.
0020 I/O CHANNEL: Selection of an input/output device
Setting entry is acceptable.
[Data type] Byte
[Valid data range] 0 to 2
The CNC provides the following interfaces for data transfer to and from
the host computer and external input/output devices:
F Input/output device interface (RS–232C serial port 1, 2)
This parameter selects the interface used to transfer data to and from an
input/output device.
Setting Description
0, 1 RS–232C serial port 1
2 RS–232C serial port 2
