Series 0i - Model A Parameter manual Page 162

Parameter manual
NOTE
1 When switching between the rigid tapping parameters on a
spindle–by–spindle basis in rigid tapping using the second
serial spindle, set this parameter to 1. The following
parameters are supported for each spindle:
2 For rigid tapping using the second serial spindle, the
multispindle control function is required.
4. DESCRIPTION OF PARAMETERS
B–63510EN/01
156
SPR In rigid tapping, the parameters are:
0 : Not changed on a spindle–by–spindle basis.
1 : Changed on a spindle–by–spindle basis.
First spindle
Second spindle
(2–stage gear) (T series only)
No.5214 No.5215
No.5221 to No.5224 No.5225, No.5226
No.5231 to No.5234 No.5235, No.5236
No.5241 to No.5244 No.5245, No.5246
No.5261 to No.5264 No.5265, No.5266
No.5271 to No.5274 No.5335, No.5336
No.5280 No.5341
No.5281 to No.5284 No.5342, No.5343
No.5300, No.5301 No.5302, No.5303
No.5310 to No.5314 No.5350 to No.5353
No.5321 to No.5324 No.5325, No.5326
5210 Rigid tapping mode specification M code
[Data type] Byte
[Valid data range] 0 to 255
This parameter sets an M code that specifies the rigid tapping mode.
To set an M code larger than 255, set it to parameter No.5212.
NOTE
1 The M code is judged to be 29 (M29) when “0” is set.
2 To use an M code whose number is greater than 255, Specify
the code number with parameter No.5212.
5211 Override value during rigid tapping extraction
[Data type] Byte
[Unit of data] 1 % or 10 %
[Valid data range] 0 to 200
The parameter sets the override value during rigid tapping extraction.
NOTE
The override value is valid when DOV in parameter No.5200
#4 is “1”.
When OVU (bit 3 of parameter No.5201) is 1, the unit of set data
is 10%. An override of up to 200% can be applied to extraction.
