Series 0i - Model A Parameter manual Page 175

Parameter manual
B–63510EN/01
4. DESCRIPTION OF PARAMETERS
169
5314 Positional deviation limit imposed during tapping axis movement in rigid tapping
[Data type] 2–word
[Unit of data] Detection unit
[Valid data range] 0 to 99999999
Usually, parameter No.5310 is used to set a positional deviation limit
imposed during tapping axis movement in rigid tapping. However,
parameter No.5314 can be used to set a value greater than the valid data
range of parameter No.5310 because of the resolution of the detector
being used.
NOTE
1 When parameter No.5314 is set to 0, the setting of
parameter No.5310 is used. When parameter No.5314 is
set to a value other than 0, parameter No.5310 is disabled;
in this case, the setting of parameter No.5314 is used.
2 When rigid tapping is performed using the second spindle
• When the SPR parameter (bit 1 of parameter No.5204)
is set to 0, the setting of parameter No.5314 (or No.5310)
is applied to the second spindle, as well as to the first
spindle.
• When the SPR parameter (bit 1 of parameter No.5204)
is set to 1, the settings of parameters No.5350 and
No.5354 are applied to the second spindle.
