Series 0i - Model A Parameter manual Page 3

Parameter manual
B–63510EN/01
PREFACE
p–1
PREFACE
The mode covered by this manual, and their abbreviations are :
Product Name Abbreviations
FANUC Series 0i–TA 0i–TA
FANUC Series 0i–MA 0i–MA
Series 0i
NOTE
1 For ease of understanding, the models are categorized as
follows:
T series: 0i–TA
M series: 0i–MA
2 Some functions described in this manual may not be applied
to some products.
For details, refer to the DESCRIPTIONS manual
(B–63502EN).
The table below lists manuals related to MODEL A of Series 0i.
In the table, this manual is marked with an asterisk (*).
Table 1 Related manuals
Manual name
Specification
Number
DESCRIPTIONS B–63502EN
CONNECTION MANUAL (HARDWARE) B–63503EN
CONNECTION MANUAL (FUNCTION) B–63503EN–1
OPERATOR’S MANUAL For Lathe B–63504EN
OPERATOR’S MANUAL For Maching Center B–63514EN
MAINTENANCE MANUAL B–63505EN
PARAMETER MANUAL B–63510EN
*
PROGRAMMING MANUAL
(Macro Compiler/Macro Executer)
B–61803E–1
FAPT MACRO COMPILER PROGRAMMING MANUAL B–66102E
Related Manuals
