DIGITAL SERVO ADAPTER Maintenance manual Page 132

Maintenance manual
APPENDIXB. LIST OF MAINTENANCE PARTS
B–63465EN/01
116
Maintenance parts (PCBs serviceable at FANUC)
Name Drawing number Vendor Remark Rank
Base printed–circuit board A16B–3200–0260 FANUC B
CPU card C A20B–3300–0171 FANUC With MMX–Pentium boot software 881I series B
CPU card A A20B–3300–0071 FANUC With 486DX2 boot software 881I series B
Axis control card
A20B–3300–0121 FANUC Two axes/high speed B
A20B–3300–0120 FANUC Four axes/high speed B
A17B–3300–0201 FANUC Six axes/high speed B
A17B–3300–0200 FANUC Eight axes/high speed B
DRAM module
A20B–3900–0042 FANUC DRAM 4M (for CPU card A) B
A20B–3900–0132 FANUC SDRAM 4M (for CPU card C) B
Memory module A20B–3900–0080 FANUC FROM 4M, SRAM 256K B
HSSB board A20B–8001–0730 FANUC B
Backpanel A20B–2002–0680 FANUC B
DPL/MDI PCB A20B–8001–0310 FANUC Dust protected type B
Maintenance parts (units serviceable at FANUC)
Name Drawing number Vender Remarks Rank
Fan unit A02B–0259–C020 FANUC B
Separate detector interface unit A02B–0236–C203 FANUC Basic four axes B
A02B–0236–C204 FANUC Expanded four axes B
FANUC, Table mount A02B-0118-C130#R FANUC For CE marking B
A02B-0118-C130#S FANUC For CE marking B
FANUC, Wall mount A02B-0118-C131#R FANUC For CE marking B
Dust protected type
A02B-0118-C131#S FANUC For CE marking B
Dust protected type
DPL/MDI
GEFANUC, Table mount A02B-0118-C132#R FANUC For CE marking B
A02B-0118-C132#S FANUC For CE marking B
GEFANUC, Wall mount A02B-0118-C133#R FANUC For CE marking B
A02B-0118-C133#S FANUC For CE marking B
