DIGITAL SERVO ADAPTER Maintenance manual Page 28

Maintenance manual
1. DISPLAY AND OPERATION
B–63465EN/01
12
When no setting/display unit is connected to the Digital Servo Adapter,
simple maintenance operations such as the display of the status of the
Digital Servo Adapter and save and restore operation of files in a batch
can be performed just using the main unit.
For details of the setting, display, and maintenance operations using the
main unit of the Digital Servo Adapter, see Appendix F.
The following items must be set on the main unit of the Digital Servo
Adapter:
Item Outline
Memory all clear Memory all clear operation using the DPL/MDI
cannot clear all the memory area. After
mounting and dismounting the memory
module or replacing it, perform all clear
operation by using the main unit of the Digital
Servo Adapter.
The following maintenance operations can be performed using the main
unit of the Digital Servo Adapter:
Item Outline
Save/restoration of SRAM data
in/from built–in FROM
When a PC board is replaced without
replacing fuses or dismounting/mounting the
memory module, SRAM data is copied.
Save/restoration in/from a
memory card in a batch
SRAM data are saved in and restored from a
memory card in a batch.
1.5
LIST OF
OPERATIONS
(MAIN UNIT)
