ALARMS
Alarm Description
Cause The value of process data such as the machining area is incorrect.
Example) A minus value is entered for an item that must be positive.
3001
Action Check the entered process data values. If there is an incorrect value,
enter a correct value.
Cause The value for the feedrate is missing or set to 0. 3005
Action Enter a correct value for the feedrate.
Cause The value for the depth of cut is missing or set to 0. 3006
Action Enter correct value for the depth of cut.
Cause The finishing allowance or radius of the tool tip radius specified for bar
machining or grooving is large. Normal rough machining cannot be
executed.
3015
Action Reduce the finishing. Alternatively, use a tool with a smaller radius at the
tool tip.
Cause Cutting in bar machining is impossible because of the relationship
between the tool angle, cutting edge angle, and clearance angle
(parameter No.9801) for the tool used.
This alarm is raised when the sum of the above three angles is less than
or equal to 90degrees or is greater than or equal to 180degrees.
3020
Action Check the above three data, and input correct values or select other tools.
Cause The figure data is incorrect in bar machining. This alarm is raised when
the relationship between start point coordinate and figures is incorrect.
3022
Action Check the machining figure. If the figure is incorrect, enter correct figure
data.
Cause A correct tool path cannot be calculated in bar machining. This alarm is
raised when there is an error in the result of internal calculation (for
example, when the value under a square root sign is negative because of
an error in calculation).
3025
Action Check the machining figure. If the figure is incorrect, enter correct figure
data. If the figure is correct, the tool or finishing amount cannot be used
for this figure. Reduce the finishing. Alternatively, use a tool with a smaller
radius at the tool tip.
Cause The groove width is incorrect in grooving. This alarm is raised when the
width of the tool used is larger than the groove width.
3026
Action Check the groove width. If the width is incorrect, enter correct value.
Otherwise, select a tool whose cutting edge width is smaller than the
groove width.
Cause Cutting in trapezoidal grooving is impossible because of the relationship of
the groove bottom width and the tool width. This alarm is raised when the
cutting edge width of the tool used is larger than the groove bottom width
in trapezoidal grooving.
3028
Action Check the figure data. If the figure is incorrect, enter correct data.
Otherwise, select a tool whose cutting edge width is smaller than the
groove width.
Cause The start point for threading coincides with the end point. 3029
Action Enter correct data for the figure.
