Series 16i/18i-MA/MB Canned Turning Cycle for Milling Machine, Specification Additional Manual Page 43

Additional Manual
GRVBCK Pecking clearance for grooving (radius).
Valid data range : 0 to 99,999,999 Units : 0.001mm
0.0001inch
OVLGRV Overlaps between each cutting in grooving (proportion to the tool width).
Valid data range : 0 to 100 Units : 1%
A.4 Parameter for Threading
ISCWCF Coefficient for the height of a inner general thread
Valid data range : 0 to 32,767 Unit:1/10000
If ISCWCF is not zero, this parameter is used for calculating the height of a inner
general thread as follows. And, for the height of a outer general thread, the
parameter 9832 is used.
If ISCWCF is zero, the parameter 9832 is used for calculating the height of a
inner or outer general thread.
Height of a inner general thread = thread pitch x ISCWCF/10000
IMUNCF Coefficient for the height of a inner metric or unified thread
Valid data range : 0 to 32,767 Unit:1/10000
If IMUNCF is not zero, this parameter is used for calculating the height of a inner
metric or unified thread as follows. And, for the height of a outer metric or
unidied thread, the parameter 9838 is used.
If IMUNCF is zero, the parameter 9838 is used for calculating the height of a
inner or outer metric/unified thread.
Height of a inner metric or unified thread = thread pitch x IMUNCF/10000
CLSCRX Default value of the clearance (diameter) of the X-axis for threading.
Valid data range : 0 to 99,999,999 Units : 0.001mm
0.0001inch
9825 OVLGRV
9824 GRVBC
K
9830 CLSCRX
9286 ISCWCF
9287 IMUNCF
