２．Specifications
2.1 Hardware specifications
Item Specification
PANEL i (Basic Unit)
CPU
Pentium III 1.26GHz or
Pentium III 866MHz or
Celeron 733MHz
Memory 128MB,256M or 512MB
LCD 15.0” color LCD (1024x768 dots, 16,000,000 colors) Display
Unit
Touch-Panel
Option (1024x1024 dots. It is not possible to push 2 points as same time.
Serial port 1 is used by this touch panel.)
keyboard
Control-Key
Function-Key /
Alphabet Key
Vert. Soft-Key
33 (Note 1)
26 (Note 1)
16 (Note 2)
Serial Port 1 1 port (Not available if touch panel option exists.)
Serial port 2 1 port
USB
2 ports (front)
1 port (rear)
(based on Universal Serial Bus Revision 1.1）
(Note) This port can't be used with Windows NT
Ⓡ
4.0.
Parallel port 1 port (Data transfer mode is by-directional mode)
Full Keyboard Keyboard port isn't available because this port is used internally.
Mouse 1 port (PS/2 compatible)
IDE
2 port/4 devices (Signal connector : IBM PC compatible)
1 port for HDD unit (basic)
1 port for CD-ROM drive (option)
Floppy disk
1 port (Signal connector : IBM PC compatible)
Ethernet
1 port (10BASE-T/100BASE-TX)
HSSB
(High Speed
Serial Bus)
1 port (An optical connector for the connection with CNC controller)
PCMCIA Card
slot
1 port (Type I/ II, based on PCMCIA 2.1)
(Note) This port can't be used with Windows NT
Ⓡ
4.0.
I/O port
I/O Link Option, 1 port to master device, 1 port to slave device
Hard Disk Drive
3.5” Hard Disk Drive 40GB
Ultra ATA/100
PCI Extension
2 slots of the short card
based on PCI specification 2.2
5V/32-bit, 33MHz
Maximum dimension of card : 176.41mm x 106.68mm
Real time clock Monthly error is within 3 minutes.
Dimension
(Height) 354.8mm, (Width) 482.6mm, (Depth) 160mm (with FDD,CD Drive)
(Depth) 140mm (without FDD,CD Drive)
Weight 10.0kg (without FDD&CD-ROMdrive unit)
Floppy Disk Drive and
CD-ROM Drive Unit
Floppy Disk Drive
3.5-inch type
2 mode
CD-ROM Drive
5-inch bay type
Weight
1.4kg
(Note 1) Key arrangement is different from MDI.
(Note 2) In case of A08B-0084-B400, B401, B402, B403, B422, B423, A13B-0196-B400, B401, B402,
B403, B422, B423, vertical soft keys signals go to only PC. In case of A08B-0084-B410, B411,
A13B-0196-B410 and B411, vertical soft keys signals go to only I/O Link. In case of
A08B-0084-B412, B413, B432, B433, A13B-0196-B412, B413, B432, B433, vertical soft keys
signals go to both PC and I/O Link. (Refer to appendix about key code to PC.)
Marked (3) are modified.
(3)
(3)
(3)
03 04.06.07 Nogami
Previous page
Next page
