4. OPERATION
B–62443EN–2/03
114
The boot system identifies a file in flash ROM by the first four characters
of the file name. When a file is read from a memory card while a file
having a file name starting with the same four characters exists, the
existing file is deleted, then the new file is read into the flash memory. The
table below lists the file names and corresponding contents. The file
names are subject to change without notice.
D Series 16/18–B/C, Series 16i/18i/21i
File name Contents File type
NC BASIC
DG SERVO
GRAPHIC
NCj OPTN
PMCj****
Basic
Servo
Graphic
Option
PMC control software, etc.
System file
PCD ****
PD1L ****
CEX!****
PMC - ****
PMC@****
P–CODE macro file/OMM
(Series 16/18–B/C)
P–CODE macro file/OMM
(Series 16
i
/18
i
/21
i
)
C executor
Ladder software
Loader ladder software
User file
A square (V) represents a single numerical character. An asterisk (*)
represents a single alphabetical character.
For the name of the P–CODE macro file of the Series 16i/18i/21i,
refer to ”FAPT MACRO COMPILER PROGRAMMING
MANUAL (B–66102).”
D Series 21–TB
File name Contents File type
MAIN NC BASIC
DG SERVO
NC1 OPTN
PMCOBSC
Basic
Servo
Option
PMC control
System file
PCD ****
PMC–RA
P–CODE macro file
PMC ladder
User file
LCB LC BASIC
PMCBBSC
Basic (for loader control)
PMC control (for loader control)
System file
PCD ****
PMC@RA
P–CODE macro file (for loader control)
PMC ladder (for loader control)
User file
An SRAM backup file on a memory card is given a name determined by
the size of the SRAM mounted on the CNC. When the size of the SRAM
is greater than or equal to 1 MB, multiple 512–KB backup files are
created.
D Series 16/18–B/C
1 2 3 4 5
256KB SRAM256A.FDB
0.5MB SRAM0_5A.FDB
1.0MB SRAM1_0A.FDB SRAM1_0B.FDB
1.5MB SRAM1_5A.FDB SRAM1_5B.FDB SRAM1_5C.FDB
2.5MB SRAM2_5A.FDB SRAM2_5B.FDB SRAM2_5C.FDB SRAM2_5D.FDB SRAM2_5E.FDB
D File names in flash
memory
D Backup file name
