LOADER CONTROL 21/16/18/160/180/16i/18i/21i/160i/180i/210i Connection manual Page 120

Connection manual
4. OPERATION
B–62443EN–2/03
120
The table below lists the G codes that can be used with the loader control
option. When the G code column and group column are divided into two,
the left–hand column indicates the G codes for the T series, while the
right–hand column indicates those for the M series.
G code Group Function
G00 Positioning (Rapid traverse)
G01
01
Linear interpolation (Cutting feed)
G02
01
Circular interpolation CW
G03 Circular interpolation CCW
G04 Dwell
G10 00 Data setting
G11 Parameter input mode cancel
G17 XpYp plane selection
G18 16 02 ZpXp plane selection
G19 YpZp plane selection
G20
06
Inch data input
G21
06
Metric data input
G22
09
04
Stored stroke limit function on
G23
09
04
Stored stroke limit function off
G27 Reference position return check
G28 Return to reference position
G30 2nd, 3rd, 4th reference position return
G31 00 Skip function
G50 G92 Coordinate system setting
G52 Local coordinate system setting
G53 Machine coordinate system selection
G54 Workpiece coordinate system 1 selection
G55 Workpiece coordinate system 2 selection
G56
14
Workpiece coordinate system 3 selection
G57
14
Workpiece coordinate system 4 selection
G58 Workpiece coordinate system 5 selection
G59 Workpiece coordinate system 6 selection
G65 00 Macro calling
G66
12
Macro modal calling
G67
12
Cancel of macro modal calling
G90
03
Absolute input
G91
03
Incremental input
4.3
PROGRAMMING
4.3.1
G Codes
