A. PARAMETERS
B–62443EN–2/03
160
Number of custom macro variables shared by the loader and NC
(macro numbers 500 to 531)
6037
Data type : Byte
Unit of data : Item
Valid data range : 0 to 32
Specify the number of custom macro variables 500 to 531 that are shared
by the loader and NC.
A custom macro variable shared by the loader and NC can be written to
and read from either the loader or NC.
[Example] When 10 is set in parameter 6037
#500 to #509 : Custom macro variables shared by the
loader and NC
#510 to #531 : Custom macro variables that are not
shared by the loader and NC
NOTE
When 0 is specified, none of custom macro variables 500
to 531 are shared by the loader and NC.
#7 #6 #5 #4 #3 #2 #1 #0
8100 NWP IAL RST
Data type : Bit
RST The reset key on the CRT/MDI panel is effective:
0 : For both the loader and NC.
1 : Only for the path displayed on the screen.
CAUTION
When setting this parameter to 1, also set bit 0 of NC
parameter 8100 to 1.
IAL When an NC alarm occurs during automatic operation, the
loader:
0 : Enters the feed hold state and stops.
1 : Continues automatic operation.
NWP The servo activation timing is:
0 : The same for the loader and NC. (Reset processing
terminates only when the NC becomes ready for activation.)
1 : Different for the loader and NC.
CAUTION
When setting this parameter to 1, also set bit 7 of NC
parameter 8100 to 1.
A.2.3
Multipath Control
Parameters
