LOADER CONTROL 21/16/18/160/180/16i/18i/21i/160i/180i/210i Connection manual Page 125

Connection manual
B–62443EN–2/03
4. OPERATION
125
NOTE
An M code not to be buffered as specified in parameters
3411 to 3420 is not buffered, irrespective of the MWB
setting.
8110 Waiting M code range (minimum value)
[Data type] : 2 words
[Valid data range]: 0 and 100 to 99999999
This parameter specifies the minimum value of the waiting M code.
The waiting M code range is specified using parameter 8110 (minimum
value) and parameter 8111 (maximum value).
(parameter 8110) v (waiting M code) v (parameter 8111)
NOTE
A value of 0 indicates that the waiting M code is not used.
8111 Waiting M code range (maximum value)
[Data type] : 2 words
[Valid data range]: 0 and 100 to 99999999
This parameter specifies the maximum value of the waiting M code.
No.
Message Description
160 MISMATCH WAITING
M–CODE
In a two–path wait
(1) The NC and loader programs
specify different M codes.
In a three–path wait
(1) The commands have identical P
values but different M codes.
(2) The commands have identical
M codes but different P values.
(3) Both two–path and three–path
wait are simultaneously speci
fied.
161 ILLEGAL P OF WAITING
M–CODE
(1) The address P value is nega
tive, 1, 2, 4, or a value greater
than 8.
(2) The specified P value conflicts
with the system configuration.
An alarm causes a single–block stop to occur, causing the path to enter the
automatic operation stop state. Meanwhile, the other path or paths stop
immediately and enter the automatic operation stop state.
D Alarms and messages
