LOADER CONTROL 21/16/18/160/180/16i/18i/21i/160i/180i/210i Connection manual Page 159

Connection manual
B–62443EN–2/03
A. PARAMETERS
159
#7 #6 #5 #4 #3 #2 #1 #0 (bit)
7902 MTX
Data type : Bit
MTX Selects whether the loader operator’s panel input/output signals
of the loader control board (TDI01 to TDI08, TDO01 to
TDO06, TCOM1 to TCOM4) are expanded as a matrix in the
range of X1010 to X1013 and Y1010 to Y1013.
0 : Matrix expansion is not performed.
1 : Matrix expansion is performed.
CAUTION
1 When matrix expansion is performed, signals TDI1 to TDI8,
TDO1 to TDO6, and TCOM1 to TCOM4 cannot be used.
The DO signals of Y1010 to Y1013 are used for LEDs hence
cannot be used for on/off control.
2 The Series 16i/18i/21i does not support matrix expansion.
Number of custom macro variables shared by the loader and NC
(macro numbers 100 to 149)
6036
Data type : Byte
Unit of data : Item
Valid data range : 0 to 50
Specify the number of custom macro variables 100 to 149 that are shared
by the loader and NC (custom macro variables shared by tool posts).
A custom macro variable that is shared by the loader and NC can be
written to and read from either the loader or NC.
[Example] When 10 is set in parameter 6036
#100 to #109 : Custom macro variables shared by the
loader and NC
#110 to #149 : Custom macro variables that are not
shared by the loader and NC
NOTE
When 0 is specified, none of custom macro variables 100
to 149 are shared by the loader and NC.
A.2.2
Parameters Related to
Custom Macros
