2. CONNECTION
51
Multiple M commands 2nd M function code signal M200 – M215 (F014 – F015)
g
2nd M function strobe signal
()
MF2 (F008#4)
g
2nd M function finish signal
()
MFIN2 (G004#4)
g
3rd M function code signal
()
M300 – M315 (F016 – F017)
g
3rd M function strobe signal
()
MF3 (F008#5)
g
3rd M function finish signal
()
MFIN3 (G004#5)
S function S function code signal
S function strobe signal
S0 – S31 (F022 – F025)
SF (F007#2)
S
function
strobe
signal
S function finish signal
SF
(F007#2)
SFIN (G005#2)
Skip function Skip signal SKIP (X1002#7)
Overtravel Over travel signal *+L1 – *+L4 (G114#0 – #3)
*–L1 – *–L4 (G116#0 – #3)
Stored stroke limit select signal EXLM (G007#6)
Loader overtravel signal *LOT (X1000#6)
Mechanical handle feed Servo off signal SVF1 – SVF4 (G126#0 – #3)
Follow–up signal *FLWU (G007#5)
External data input 1) External alarm message function
)g
2) External operation message function
)g
3) External program number search function
)g
Data signal ED00 – ED15 (G000 – G001)
g
Address signal
()
EA0 – EA6 (G002#0 – #6)
g
Read signal
()
ESTB (G002#7)
g
Read finish signal
()
EREND (F060#0)
g
Search finish signal
()
ESEND (F060#1)
Custom macro Input signal for custom macro UI0 – UI15 (G054 – G055)
Output signal for custom macro UO0 – UO15 (F054 – F055)
UO100 – UO131 (F056 – F059)
Interrupt signal for custom macro UINT (G053#3)
Position switch function Position switch signal PSW01 – PSW10 (F070#0 – F071#1)
