6.MACRO EXECUTOR FUNCTION B-63943EN-2/01

- 112 -

Variable No. Function Type R/W

Conversational

Auxiliary

Execution

#8518 (1 whenever used) Integer R/W

¡¡

#8519 Array start variable number Integer R/W

¡¡

Torque limit override control

#8621 to #8628 Torque limit override values for the 1st to 8th servo axes Integer R/W

¡¡¡

#8990 Read/write selection Integer R/W

¡¡¡

#8991 Axis number Integer R/W

¡¡¡

#8992 Torque limit override value Integer R/W

¡¡¡

#8993 Completion code Floating R/

¡¡¡

PMC axis control

#8602 PMC controlled axis selection Integer R/W

¡¡

#8700

PMC controlled axis selection variable (macro variable

command type)

Integer R/W

¡¡

#8710,#8720

#8730,#8740

PMC command signal variable Integer R/W

¡¡

#8711,#8721

#8731,#8741

PMC control command variable Integer R/W

¡¡

#8712,#8722

#8732,#8742

PMC cutting feed variable Integer R/W

¡¡

#8713,#8723

#8733,#8743

PMC control travel distance variable Integer R/W

¡¡

#8715,#8725

#8735,#8745

Variables for reading PMC status signals Integer R/W

¡¡

Axis-direction-by-axis-direction interlock function

#8600 (1 to 16 axes)

#8607 (17 to 32 axes)

Axis-direction-by-axis-direction interlock control variables Integer R/W

¡¡

#8601 (1 to 16 axes)

#8608 (17 to 32 axes)

Movement axis and direction variables for the rise time of the

SKIP signal

Integer R/

¡¡

Window function

#8996 Completion code Integer R/

¡¡

#8997 Axis number Integer R/W

¡¡

#8998 System information ID Integer R/W

¡¡

#8999 System information Floating R/

¡¡

Function for searching data tables for control variables

#8650

Start macro variable number in the search target data table

(for READ)

Start macro variable number in the set next to the retrieved

data table set number (#8655) (for WRITE)

Integer R/W

¡¡

#8651 The number of macro variables forming a set in the data table Integer R/W

¡¡

#8652

The number of search target data table sets (for READ)

Set value minus the number of sets that have already been

retrieved (for WRITE)

Integer R/W

¡¡

#8653 Lower limit to the search value Floating R/W

¡¡

#8654 Upper limit to the search value Floating R/W

¡¡

#8655

The data table set number where a control variable that

satisfies the search condition is contained

Integer R/

¡¡
