6.MACRO EXECUTOR FUNCTION B-63943EN-2/01

- 136 -

6.1.3.5 Character display (G243)

This code displays characters.

Format

G243 Xx Yy Aa Bb Cc Kk Ff.e Dd *** Pp

( _ ) ( ' _ ' ) ( *_* ) ;

- Addresses X and Y

Addresses X and Y are used to specify the display position of the

character string in the character coordinate system.

X : X coordinate of the display position of the character string

Y : Y coordinate of the display position of the character string

NOTE

1 When specifying both X and Y, specify them in

succession.

2 The commands of addresses X and Y are:

- Absolute commands at all times when bit 3

(INCD) of compile parameter (No. 9167) is set to

- Switched between absolute and incremental

commands by G390/G391 when bit 3 (INCD) of

compile parameter (No. 9167) is set to 1.

-( _ )

( and ) are used to directly specify the character string to be displayed.

The characters that can be enclosed in ( and ) are the alphabetic

characters (uppercase only), digits, the minus sign, the decimal point,

and spaces.

Example

G243(FANUC);

"FANUC" is displayed.

- ( ‘_’ )

(' and ') are used to specify the character string (of single- and double-

byte characters) to be displayed. The characters that can be enclosed

in (' and ') are the characters given in the Katakana Code Table and

the Chinese and Hiragana Code Table in Appendix B.

Hiragana and Chinese characters each take a space twice wider than a

single-byte character.

Example

G243(' ');;

" " is displayed.
