3.EXECUTION MACRO FUNCTION B-63943EN-2/01

- 60 -

User program

Compile parameter (No.9013)=81

O9010 ;

M300 P100 L2 ;

M99 ;

Compile parameter

(No.9033)=300

O0001 ;

G81 X10.0 Z-10.0 ;

M30

;

Mm P p L l ;

m : Call M code

P : Program number of a execution program to be called

l : Repetition count (1 by default)

1 to 999999999

Execution macro

O0100 ;

M99 ;

3.2.18 Subprogram Call for User Program

A user program is called as a subprogram using the M code specified

for compile parameter (No. 9033).

Format

Nesting and local variables

Each subprogram call for a user program is assumed to call a custom

macro as a subprogram using M98 and is counted among custom

macro nesting levels.

The local variables at the calling execution macro are passed,

regardless of the state of bit 3 (LCLLV) of compile parameter (No.

9163).

Limitation

1 If an M code exceeding 99999999 is set, the call is invalidated.

(The M code is output as an ordinary M code.)

2 Usually, when a called user program calls another program, the

G65/G66/G66.1/M98 command only can be specified. The

restriction to be applied to bit 6 (GMP) of parameter (No. 6008)

differs from the restriction to be applied to bit 2 (PCDC) of

compile parameter (No. 9163).
