B-63943EN-2/01 3.EXECUTION MACRO FUNCTION

- 27 -

3.2.2 Modal Call (G66/G66.1)

A modal call is performed for the execution macro specified at

address P.

The functions such as move command call (G66) operation, block-by-

block call (G66.1) operation, and multi-level modal calls are exactly

the same as for custom macros. See the specifications of custom

macros as well.

Format

Limitation

• No execution macro can be called from any user program using

this command. This command can be specified only for calling

an execution macro from another execution macro.

• This command can be specified only when bit 2 (PCDC) of

compile parameter (No. 9163) is set to 1.

G66 P p L l <argument-

specification> ;

G66 : Call command.

Must be specified before any argument.

P : Program number of an execution macro to

be called

l : Repetition count (1 by default)

1 to 999999999

argument : Data to be passed to the execution

macro. Argument specifications I and II

are available. Arguments only in G66

blocks are passed to local variables.

O9010 ;

G66 P100 L2 A1.0 B2.0 ;

G00 G90 X100.0 ;

Y200.0

X150.0 Y300.0

G67 ;

M99 ;

O0100 ;

G00 Z-#1 ;

G01 Z-#2 F300 ;

M99 ;

Execution macro Execution macro

G66.1 P p L l <argument-

specification> ;

G66.1: Call command.

Must be specified before any argument.

P : Program number of an execution macro to be

called

l : Repetition count (1 by default)

1 to 999999999

argument : Data to be passed to the execution

macro. Argument specifications I and II

are available.

Execution macro

O9010 ;

G66.1 P100 L2 A1.0 B2.0

F100;

10.0 B20.0 F300 ;

0 B-30.0 ;

F1000 ;

G67 ;

M99 ;

O0100 ;

G00 Z-#1 ;

G01 Z-#2 F#9 ;

M99 ;
