3.EXECUTION MACRO FUNCTION B-63943EN-2/01

- 40 -

NOTE

The specifiable addresses and specification range

conform to the specification address range of the

CNC. For example, address M does not allow the

decimal point to be used. So, the specification of

T123 M1.23; results in alarm PS0007.

Limitation

• Usually, when an execution macro is called from a program

called using a T code, only a G65 or M98 command can be

specified. When bit 2 (PCDC) of compile parameter (No.

9163) is set to 1, G66 and G66.1 are also usable.

• When bit 2 (PCDC) of compile parameter (No. 9163) is set to 1,

a call using a G code can be made from a program called using a

T code by setting bit 6 (GMP) of parameter (No. 6008) to 1.

This parameter is an ordinary parameter, so that this parameter

can be modified, for example, through the MDI panel.

• No repetition count can be specified because address L is also

used as an argument.

• No specified address is evaluated. So, an execution macro is

called by a specified address without making a modal change.
