2.2 INSTALLATION AND UN INSTALLATION
This chapter explains how to install the PMC Simulator and its attached
programs in your PC, as well as how to uninstall them from it. The
CD-ROM disk is common to the PMC simulator and the CNC
simulator.
Note
1 Do not insert the USB protect key in the PC until
the installation of the FANUC simulator is finished.
2 The privilege of Administrators is necessary in the
installation of the FANUC simulator.
2.2.1 Installation procedure
1 Preparation prior to installation
1-1 Before installation, see Section 2.1, "OPERATING
ENVIRONMENT" to check the environment of the computer
being used.
2 Starting the installer
2-1 If any programs are running, exit them.
2-2 Set the disk in the CD-ROM drive. Windows automatically
starts installation.
2-3 If Windows does not automatically start installation, click
[Start Menu] - [Run]. Type the following in the Open field,
and then click <OK>
(CD-ROM drive name):¥AutoRun.exe
3 Starting setup and confirming the license agreement of .NET
Framework
Because this product requires Microsoft .NET Framework1.1
(SP1) (referred to as .NET Framework in the remainder of this
manual), the .NET Framework installer starts first. If your PC
already has .NET Framework installed, this installer does not start.
If so, go to step "4."
After .NET Framework has been installed, the CNC Simulator
installer starts next.
