FANUC PMC Simulator, Operator Additional Manual Page 6

Additional Manual
FANUC PMC Simulator
Operator’s Manual
01 05.08.01
T.Maruyama
New registration
A-90139EN/01
EDIT
DATE
DESIG.
DESCRIPTION
6/70
DRAW.NO.
• The debugging ladder that cooperates with the CNC simulator is
possible in the coordinated CNC/PMC simulator mode.
Display and operation of CNC screen
Ladder using the functional instruction related to CNC
Ladder using the signal related to CNC(G,F)
• The correspondent functions of the CNC/PMC simulator in the
coordinated mode is as follows.
Table 1.1.2 (a) Correspondent functions of CNC/PMC simulator in the
coordinated mode
Function Correspondent
Window functional instruction (Exclude the servo/spindle
data)
DISPB (message display) functional instruction and EXIN
(external data input) functional instruction
AXCTL (PMC axis control) functional instruction and signal
related to PMC axis control function
×
Signal related to auxiliary function
Signal related to tool functions
Signal related to spindle speed function
×
Signal related to high-speed position switch and position
switch
×
Signal related to measurement function (high-speed skip
and skip, etc.)
×
Signal related to Reference position establishment
×
: available × : unavailable
