FANUC PMC Simulator, Operator Additional Manual Page 22

Additional Manual
FANUC PMC Simulator
Operator’s Manual
01 05.08.01
T.Maruyama
New registration
A-90139EN/01
EDIT
DATE
DESIG.
DESCRIPTION
22/70
DRAW.NO.
3.1.2 Exiting PMC simulator
There are the following two kinds of operations depending on the
display mode of the simulator.
PMC simulator, Window mode of CNC/PMC simulator:
On the [File] menu, click [Exit]. Alternatively, click
(<Close>
button) in the upper right corner of the parent window.
Picture mode of CNC/PMC simulator:
To exit the simulator, click the Exit button located at the lower left
corner of the simulator screen. Alternatively, select to exit in the
popup menu by right-clicking the mouse.
Exit button Popup menu
Fig.3.1.2 Exit simulator
Note
Refer to "4.3.1 Display mode" about the display
mode in coordinated CNC/PMC simulator mode.
