- When the tool posture is closer to a singular point posture on a 5-axis machine
If tool direction compensation is performed on a 5-axis, and the tool posture gets
closer to a singular point posture during execution of a block, the rotation axis
closer to the workpiece may make a large motion.
And, when the parameter No.11204(Angle to decide singular posture) has a value,
the rotary axis closer to the tool may rapidly move by the angle. Therefore, so
large a value should not be set to the parameter No.11204.
- Notes in the case that rotary axes have movable range
When the tool direction is compensated(Parameter RCM (No.11200#0)=1) on a 5-
axis machine, there can be the case that the machine position does not pass the
singular posture during a progress of work at all.
In this case, in accordance with 4) described above, the solution with which the
rotary axes don’t pass the singular position is always selected. Therefore, in this
case, the movement direction(area) depends where the tool firstly exists in
comparison with the singular position, because the tool position is always
selected so that the rotary axes don’t pass the singular position.
In the case that rotary axes have movable range and a singular position exists in
that range, Workpiece setting error compensation must be activated after the
rotary axes have been moved to the range where the rotary axes should move,
that is, the range (A) between the lower limit and the singular position or the
range(B) between the upper limit and the singular position.
Generally speaking, if (A) and (B) are different, it is recommended that the larger
one is selected.
Movable range o
f
rotary axis
Lower limit o
f
movable range
Upper limit o
f
movable range
Singular position
0deg
(A) (B)
Workpiece setting error compensation must be activated after the
rotary axes have been moved to the range where the rotary axes
should move
