FANUC Series 30i-MODEL A, Series 31i-MODEL A5, Series 31i-MODEL A Workpiece setting error compensation Additional Manual Page 43

Additional Manual
FANUC Series 30i/31i-MODEL A/31i-MODEL A5
Workpiece Setting Error Compensation
A
-79634E
4
3
/
75
Ed. Date Design Description
Date Feb.08.’05 Design. Apprv.
page
Title
Draw
No.
- Mirror image
If workpiece setting error compensation and programmable mirror image are
used at the same time, programmable mirror image is applied to the coordinates
in the workpiece setting coordinate system, then workpiece setting error
compensation is applied.
If workpiece setting error compensation and external mirror image (mirror image
based on a mirror image signal or setting) are used at the same time, workpiece
setting error compensation is first applied, then external mirror image is applied.
Workpiece coordinate system
Y
Workpiece setting coordinate system
Mirror center
Programmed path
A
ctual path
X
X'
Y
'
Workpiece coordinate system
Y
Workpiece setting coordinate system
Mirror-applied position
Programmed path
A
ctual path
X
X'
Y
'
