  2. FANUC Series 30i-MODEL A, Series 31i-MODEL A5, Series 31i-MODEL A Workpiece setting error compensation

FANUC Series 30i-MODEL A, Series 31i-MODEL A5, Series 31i-MODEL A Workpiece setting error compensation Additional Manual Page 53

Additional Manual
FANUC Series 30i/31i-MODEL A/31i-MODEL A5
Workpiece Setting Error Compensation
A
-79634E
53
/
75
Ed. Date Design Description
Date Feb
.08.’05 Design. Apprv.
page
Title
Draw
No.
19680 Mechanical unit type
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 0 to 21
Specify the type of the mechanical unit.
PRM19680
Mechanical
unit type
Controlled rotation
axis
Master and slave
0
Mechanism having no
rotation axis
2
Tool rotation
type
Two rotation axes of
the tool
The first rotation axis is the
master, and the second rotation
axis is the slave.
12
Table rotation
type
Two rotation axes of
the table
The first rotation axis is the
master, and the second rotation
axis is the slave.
21 Mixed type
One rotation axis of
the tool + one rotation
axis of the table
The first rotation axis is the tool
rotation axis, and the second
rotation axis is the table rotation
axis.
First rotar
y
axis
(
master
)
Second rotar
y
axis
(
slave
)
First rotary axis (master)
Second rotary axis (slave)
Tool rotary
axes
Table rotary
axes
NOTE
A hypothetical axis is also counted as a controlled rotary axis.
<Hypothetical axis>
In some cases, it is convenient to use an imaginary rotary axis
whose angle is fixed to a certain value. For example, suppose
that a tool is mounted in a tilted manner through an attachment.
In such a case, the rotary axis considered hypothetically is a
hypothetical axis. Bits 0 and 1 of parameter No. 19696
determine whether each rotary axis is an ordinary rotary axis or a
hypothetical axis.
Previous page
Next page
