(Replace the “4.5.5.3 Password”)
4.5.5.3 Password
(1)Password
To decompile a password-protected file, it is necessary to enter a password.
Set password type Password type to be
entered
Both password(R) and password(R/W) Password (R/W)
Password(R/W) Password (R/W)
Password (R) Password (R)
①After the discompilation [EXEC] is selected, the following password entry screen
appears.
Note) If an R/W password has been set up, “Password(R/W)” is displayed.
②When the valid password is entered, discompilation begins.
If the newly entered password is incorrect, an error message is displayed, and
processing discontinues.(You are allowed to retry entering twice.)
When <Esc> is pressed, the request to start discompilation is rejected.
(2)Special password
There are two ways of decompilations of an object file with a special
password as follows.
(a)Decompilation of all programs (Necessary a special password input)
The procedure of a decompilation is similar to that of an object protected
by a 'non-special' password. Refer to "(1)password".
(b)Decompilation of non-protected subprograms area only
(Not necessary a special password input)
In OFF-LINE FUNCTION, it is possible to edit only non-protected subprograms
area,
(A printout is also possible. But it is impossible to convert to a mnemonic file
because a source program of a protected area is not created.)
Re-compilation after modifying of non-protected area is possible. But the
password set function is disabled. A special password in a decompiled object file
is automatically embedded and the protected area is re-protected.
