D. OPTICAL CABLE
B–63463EN/01
APPENDIX
120
3. Procuring the cable
All the optical fiber cables mentioned above are special cable products
with optical connectors, which are designed, produced, and tested to
ensure the required system performance and reliability. It is
technically impossible for users to produce these cables or process (cut
and reconnect) them after purchase. Users are requested to purchase
cables of the necessary length from an appropriate supplier. Cables are
available from either FANUC or any of the FANUC–approved
manufacturers listed in Table D (b).
Table D (b) FANUC–approved cable manufacturers and cable model
numbers (retail)
(1)Internal cord type cable: A66L–6001–0023#LjRjjj
Manufacturer Model number Remarks
Japan AMP, Co., Ltd. *–353373–*
Japan Aviation Electronics
Industry, Ltd.
PF–2HB209–**M–F–1
** indicates the cable
length (m).
Hirose Electric Co., Ltd. H07–P22–F2VCFA–**
** indicates the cable
length (m).
(2)External cable: A66L–6001–0026#LjRjjj
Manufacturer Model number Remarks
Japan AMP, Co., Ltd. *–353199–*
Japan Aviation Electronics
Industry, Ltd.
CF–2HB208–**M–F–1
** indicates the cable
length (m).
Hirose Electric Co., Ltd. H07–P22–F2NCFA–**
** indicates the cable
length (m).
Oki Electric Cable Co., Ltd. OPC201HPXF–**MB
** indicates the cable
length (m).
NOTE
Cables other than those of standard lengths cannot be
purchased from FANUC.
