DIGITAL SERVO ADAPTER Connection manual Page 62

Connection manual
7. CONNECTION TO PERIPHERALS
B–63463EN/01
54
JD42
(PCR–EV20MDT)
1 RDA 11 SDA
20V120V
3 DRA 13 ERA
40V140V
5 CSA 15 RSA
60V160V
7 CDA 17 (SDB)
8 0V 18 (0V)
9 (RDB) 19
10 20
Relay connector
(DBM–25S)
1FG14
2 SDA 15
3 RDA 16
4 RSA 17
5 CSA 18
6 DRA 19
7 SG 20 ERA
8 CDA 21
922
10 23
11 24
12 25 +24V
13
24–VDC
regulated
power supply
1.0A
J146B
Relay connector
(FANUC purchase specification: A02B–0061–K201)
– D–SUB 25–pin female connector:
DBM–25S (Japan Aviation Electronics Industry, Ltd.)
– Locking bracket:
D20418–J2 (Japan Aviation Electronics Industry, Ltd.)
Digital Servo Adapter
Cable connector (FANUC purchase specification: A02B–0118–K895)
D D–SUB 25–pin male connector with a cover: DBM–25P (Japan
Aviation Electronics Industry, Ltd.)
D Locking bracket: DB–C2–J9 (Japan Aviation Electronics Industry,
Ltd.)
24–VDC regulated power supply
Used for FANUC I/O devices of the 24–V power type such as the
HANDY FILE
24 VDC (10% (including instantaneous changes and ripples)
The power can also be supplied via the power connector CP2 of the
Digital Servo Adapter.
The above cable may be purchased from FANUC as a punch panel.
The punch panel is equipped with a terminal block for connection to the
24–VDC power. A separate 24–VDC cable is required.
D Punch panel (length: 1 m): A02B–0259–C191
D Punch panel (length: 2 m): A02B–0259–C192
D Punch panel (length: 3 m): A02B–0259–C193
7.2.2
RS–232–C Serial Port
