7. CONNECTION TO PERIPHERALS
B–63463EN/01
72
To use servo check boards with the Digital Servo Adapter, servo check
board adaptor A02B–0236–K822 is required. This adaptor is provided
with a cable for connection to the Digital Servo Adapter.
For a detailed explanation of how to connect and use the servo check
boards, refer to the “FANUC AC SERVO MOTOR α series Parameter
Manual” or other relevant manuals.
1 A servo check board must be connected only when it is to be used. As
soon s the board is no longer needed, remove it.
2 Up to two digital servo check boards can be used at one time. If three
or more boards are to be used at one time, contact FANUC.
3 Only one analog servo check board can be used at a time. If two or
more boards are to be used at a time, contact FANUC.
4 Use the attached cable. The cable length cannot be extended.
7.5.2
Servo Check Boards
7.5.3
Notes on Use
