DIGITAL SERVO ADAPTER Connection manual Page 45

Connection manual
B–63463EN/01
6. CONNECTION USING THE HSSB
37
NOTE
For the 2–channel type, switch A corresponds to COP7A
and switch B corresponds to COP7B. Those parts whose
names end with B are for the second channel.
NOTE Notes on handling the HSSB PC interface board
1 Measures against static electricity
The interface board is put in an anti–static bag before shipment. Before storage and transport,
be sure to put it in this bag. When taking it out and handling it, be sure to ground yourself.
2 Protection of the card edge terminal
When handling the interface board, never touch the card edge terminal (gold coated portion
to be in contact with the connector). If you should touch it, wipe it gently with clean absorbent
cotton (which may be soaked with ethyl alcohol). Do not use any other chemicals other than
ethyl alcohol.
Beware of static electricity.
Do not touch the terminal.
