B-65232EN/03 DESCRIPTIONS FOR FANUC AC SERVO MOTOR β series 5.IEC34 STANDARD

- 41 -

5.2 APPROVAL SPECIFICATIONS

5.2.1 Rotational Speed (IEC34-1)

Each model's maximum allowable speed is as shown below.

The maximum allowable speeds are determined from the viewpoint of

speed alone within the range in which the certification condition for

satisfying the IEC34 standard is observed. The characteristics at a

maximum allowable speed are not guaranteed.

Motor model

Rated speed

(min

-1

)

Maximum allowable speed

(min

-1

)

βM0.4/4000

βM0.5/4000

βM1/4000

4000

4000

4000

5000

5000

5000

β1/3000

β2/3000

β3/3000

β6/2000

3000

3000

3000

2000

4000

4000

4000

3000

(*) The maximum allowable speeds are applicable only when HRV

control is used for driving.

5.2.2 Output (IEC34-1)

The rated output is guaranteed as continuous output only at the rated

output speed.

Output in the intermittent operating zone is not specified. The

certified output value of each model is indicated below.

Motor model

Rated output

(W)

βM0.4/4000

βM0.5/4000

βM1/4000

125

200

400

β1/3000

β2/3000

β3/3000

β6/2000

300

500

500

900
