B-65232EN/03 DESCRIPTIONS FOR FANUC AC SERVO MOTOR β series 5.IEC34 STANDARD

- 43 -

5.2.5 Installation Method (IEC34-7)

A motor can be installed using any of the following methods:

IMB5 : The motor is installed by using a flange, with the

shaft oriented horizontally (from the back).

IMV1 : The motor is installed by using a flange, with the

shaft oriented upwards (from the back).

IMV3 : The motor is installed by using a flange, with the

shaft oriented downwards (from the back).

5.2.6 Heat Protection (IEC34-11)

The heat protection mode defined in IEC34-11 is as follows:

Motor model Code Method

β6/2000 TP112

Indirect protection of windings by means of a

thermal cut-out

T P 1 1 2

2 : Temperature rise limit class 2 for heat protection

1 : One-stage stop only

(with no alarm information output)

1 : Protection against less abrupt overload only

NOTE

1 Heat protection is not defined for models other than

the model indicated above.

2 Each model is software-protected against an

abrupt overload.
