OPERATION

B–62094E/04

7. ALARM AND SELF–DIAGNOSIS

FUNCTIONS

283

Ending PMC data display

Pressing <NO.>, <Number>, and <INPUT> redisplays the diagnosis

screen.

Setting PMC data

PMC data can be set from the DPL/MDI when setting parameter DWE

is set to 1.

1 Select the setting parameter display.

2 Use the cursor keys to position the cursor on DWE.

Press <1> and <INPUT> to set DWE to 1.

WARNING

When not setting PMC data, set DWE to 0 so that PMC data

is not set inadvertently.

3 Select a PMC address and enter a number.

> D0100 00000000

D0101 00001010

Example: Enter 100 in decimal in the

address data of D0100.

4 Press the < · > key to select a data format.

> D0100 0

D0101 10

Example: Select 1-byte decimal.

5 Use the numeric keys to enter a value.

> D0100 0

D0100= 100_

6 Press the <INPUT> key.

The data value is input and displayed.

> D0100 100

D0101 10

NOTE

The range of values that can be entered in each data format

is as follows:

1 byte of flag bits : 8 independent bits, each only taking

either 0 or 1.

1-byte decimal : –128 to 127

2-bytes decimal : –32768 to 32767

4-bytes decimal : –99999999 to 99999999

Procedure


