POWER MATE-D/F Operators manual Page 329

Operators manual
OPERATION
8. DATA INPUT/OUTPUT
B–62094E/04
312
The file with the specified file number is deleted.
Deleting files
1 Press the EDIT switch on the machine operator’s panel.
2 Press function key
PROG
.
3 Press the rightmost soft key
(next–menu key).
4 Press soft key [FLOPPY].
5 Press soft key [(OPRT)].
6 Press soft key [DELETE].
EDIT
* * * *
* * * * * *
DELETE
FILE NO. =
>_
O0001 N00000
(METER) VOL
DIRECTORY (FLOPPY)
NO. FILE NAME
CAN
F SET
EXEC
F NAME
NAME=
11:55:51
7 Specify the file to be deleted.
When specifying the file with a file number, type the number and
press soft key
[F SET].When specifying the file with a file name, type
the name and press soft key
[F NAME].
8 Press soft key
[EXEC].
The file specified in the file number field is deleted. When a file is
deleted, the file numbers after the deleted file are each decremented
by one.
9 Press soft key
[CAN] to return to the soft key display shown in the
screen of Fig. 8.8.1(a).
If
[F SET] or [O SET] is pressed without key inputting file number and
program number, file number or program number shows blank. When
0 is entered for file numbers or program numbers, 1 is displayed.
8.8.4
Deleting Files
 

D Inputting file numbers
and program numbers
with keys
