APPENDIX

G. ALARM LIST

B–62094E/04

442

6) Over travel alarms

Number Message Contents

500 OVER TRAVEL : +n Exceeded the n–th axis (axis 1–2) + side stored stroke limit I.

(Parameter No.1320 Notes)

501 OVER TRAVEL : –n Exceeded the n–th axis (axis 1–2) – side stored stroke limit I.

(Parameter No.1321 Notes)

7) Overheat alarms

Number Message Contents

700 OVERHEAT: CONTROL UNIT Control unit overheat

Check that the fan motor operates normally, and clean the air filter.

701 OVERHEAT: FAN MOTOR The fan motor on the top of the cabinet for the contorl unit is over-

heated. Check the operation of the fan motor and replace the motor if

necessary.

704 OVERHEAT: SPINDLE Spindle overheat in the spindle fluctuation detection

(1) If the cutting load is heavy, relieve the cutting condition.

(2) Check whether the cutting tool is share.

(3) Another possible cause is a faulty spindle amp.

8) Spindle alarms

Number Message Contents

749 S–SPINDLE LSI ERROR A communication error occurred for the serial spindle. The cause may

be the disconnection of an optical cable or the interruption of the power

to the spindle amplifier.

(Note) Unlike alarm No. 750, this alarm occurs when a serial commu-

nication alarm is detected after the spindle amplifier is normally acti-

vated.

750 SPINDLE SERIAL LINK START

FAULT

This alarm is generated when the spindle control unit is not ready for

starting correctly when the power is turned on in the system with the

serial spindle.

The four reasons can be considered as follows:

1) An improperly connected optic cable, or the spindle control unit’s

power is OFF.

2) When the NC power was turned on under alarm conditions other

than SU–01 or AL–24 which are shown on the LED display of the

spindle control unit.

In this case, turn the spindle amplifier power off once and perform

startup again.

3) Other reasons (improper combination of hardware)

This alarm does not occur after the system including the spindle

control unit is activated.

4) The second spindle (when SP2, bit 4 of parameter No. 3701, is 1)

is in one of the above conditions 1) to 3).

See diagnostic display No. 409 for details.

751 FIRST SPINDLE ALARM DETEC-

TION (AL–XX)

This alarm indicates in the NC that an alarm is generated in the spindle

unit of the system with the serial spindle. The alarm is displayed in form

AL–XX (XX is a number). Refer to (11) Alarms displayed on spindle

servo unit .The alarm number XX is the number indicated on the

spindle amplifier. The CNC holds this number and displays on the

screen.

752 FIRST SPINDLE MODE CHANGE

FAULT

This alarm is generated if the system does not properly terminate a

mode change. The modes include the spindle positioning, rigid tapping,

and spindle control modes. The alarm is activated if the spindle control

unit does not respond correctly to the mode change command issued

by the NC.
