POWER MATE-D/F Operators manual Page 405

Operators manual
OPERATION
11. SETTING AND DISPLAYING DATA
B–62094E/04
388
Various run times, the total number of machined parts, number of parts
required, and number of machined parts can be displayed. This data can
be set by parameters or on this screen (the total number of machined parts
and the time during which the power is on can be set only by parameters).
Procedure for Displaying and Setting Run Time and Parts Count
1 Select the MDI mode.
2 Press function key
OFFSET
SETTING
.
3 Press chapter selection soft key
[SETING].
4 Press page key
PAGE
or
PAGE
several times until the following screen
is displayed.
SETTING (TIMER) O0001 N0000
> _ S 0 T0000
MDI **** *** ***
16:05:59
[ OFFSET ][ SETING ][ WORK ][ ][(OPRT)]
PARTS TOTAL = 14
PARTS REQUIRED = 0
PARTS COUNT = 23
POWER ON = 4H 31M
OPERATING TIME = 0H 0M 0S
CUTTING TIME = 0H 37M 5S
FREE PURPOSE = 0H 0M 0S
CYCLE TIME = 0H 0M 0S
DATE = 1993/07/05
TIME = 11:32:52
5 To set the number of parts required, move the cursor to PARTS
REQUIRED and enter the number of parts to be machined.
6 To set the clock, move the cursor to DATE or TIME, enter a new date
or time, then press soft key [INPUT].
This value is incremented by one when M02, M30, or an M code specified
by parameter 6710 is executed. This value cannot be set on this screen.
Set the value in parameter 6712.
It is used for setting the number of machined parts required.
When the “0” is set to it, there is no limitation to the number of parts.
Also, its setting can be made by the parameter (NO. 6713).
This value is incremented by one when M02, M30, or an M code specified
by parameter 6710 is executed. The value can also be set by parameter
6711. In general, this value is reset when it reaches the number of parts
required. Refer to the manual issued by the machine tool builder for
details.
11.4.4
Displaying and Setting
Run Time and Parts
Count
Procedure for CRT/MDI
Display items
D PARTS TOTAL
D PARTS REQUIRED
D PARTS COUNT
