POWER MATE-D/F Operators manual Page 316

Operators manual
OPERATION
B–62094E/04
8. DATA INPUT/OUTPUT
299
5 NC parameters are input to the memory by this operation. Normally,
alarm PS000 will activate after completion of parameter reading.
Normally, P/S alarm 000 is generated after parameters have finished
being read in.
6 Set PWE on the setting parameter to 0.
7 Turn on the NC power again if PS alarm activates.
8 Release the emergency stop button of machine side.
All parameters are output in the defined format from the memory of the
controller to a floppy or NC tape.
Outputting parameters
1 Make sure the output device is ready for output.
2 Specify the punch code system (ISO or EIA) using a parameter.
3 Press the EDIT switch on the machine operator’s panel.
4 Press function key
SYSTEM
.
5 Press chapter selection soft key
[PARAM].
6 Press soft key
[(OPRT)].
7 Press rightmost soft key
(next–menu key).
8 Press soft keys [PUNCH] and [EXEC].
All parameters are output in the defined format.
1 Select the EDIT mode.
2 Select the parameter display screen by <PARAM> key.
3 Press the <WRITE> key.
4 Execute file heading when required.
For which file the parameter is output to, refer to 8.4.2.
5 While parameter, is being output, the display appears as below.
>&0100 00000000
WRITE
6 In order to stop output of data from a tape before it has finished,
turn on external reset signal ERS (bit 7 of G008).
Once data output from a tape has been stopped, it cannot be
restarted.
8.6.2
Outputting Parameters
 
 
