POWER MATE-D/F Operators manual Page 71

Operators manual

Page of 475

/ 475

PROGRAMMING

5. FEED FUNCTIONS

B–62094E/04

Dwell G04 X_ ; or G04 P_ ;

X_ : Specify a time (decimal point permitted)

P_ : Specify a time (decimal point not permitted)

By specifying a dwell, the execution of the next block is delayed by the

specified time. In addition, a dwell can be specified to make an exact

check in the feed at programmed rate.

When neither P nor X is specified, exact stop is performed.

Table 5.5 (a) Command value range of the dwell time

(Command by X)

Increment system Command value range Dwell time unit

IS–B

0.001 ∼ 99999.999

second

IS–C

0.0001 ∼ 9999.9999

second

Table 5.5 (b) Command value range of the dwell time

(Command by P)

Increment system Command value range Dwell time unit

IS–B 1 ∼ 99999999 0.001 sec

IS–C 1 ∼ 99999999 0.0001 sec

5.5

DWELL (G04)

Format

Explanations
