OPERATION

B–62094E/04

11. SETTING AND DISPLAYING DATA

369

Displays the following positions on a screen : Current positions of the

tool in the workpiece coordinate system, relative coordinate system, and

machine coordinate system, and the remaining distance. The relative

coordinates can also be set on this screen. See subsection 11.1.2 for the

procedure.

Procedure for Displaying Overall Position Display Screen

1 Press function key

POS

2 Press soft key

[ALL].

(RELATIVE)

X 246.912

Y 913.780

(WORK)

X 123.456

Y 456.890

(MACHINE)

X 0.000

Y 0.000

(DISTANCE TO GO)

X 0.000

Y 0.000

AUTO **** *** *** 09:06:35

[ WORK ] [ REL ] [ ALL ] [ HNDL ] [(OPRT)]

ACTUAL POSITION O1000 N00010

PART COUNT 5

RUN TIME 0H15M CYCLE TIME 0H 0M38S

ACT.F 3000 MM/M

S 0 T0000

The current positions of the tool in the following coordinate systems are

displayed at the same time:

⋅ Current position in the relative coordinate system

(relative coordinate)

⋅ Current position in the work coordinate system

(work coordinate)

⋅ Current position in the machine coordinate system

(machine coordinate)

⋅ Distance to go (distance to go)

The distance remaining is displayed in the AUTO or MDI mode. The

distance the tool is yet to be moved in the current block is displayed.

The least command increment is used as the unit for values displayed in

the machine coordinate system. However, the least input increment can

be used by setting bit 0 (MCN) of parameter 3104.

On the overall position display screen, relative coordinates can be reset

to 0 or preset to specified values. Use the same procedure used to reset

relative coordinates (Section 11.1.2).

11.1.3

 



Procedure for CRT/MDI

Explanations

D  

D   

D  



D  


