OPERATION12. GRAPHICS FUNCTION

B–64114EN/01

656

It is possible to draw the programmed tool path on the screen, which

makes it possible to check the progress of machining, while observing the

path on the screen.

In addition, it is also possible to enlarge/reduce the screen.

The drawing coordinates (parameter) and graphic parameters must be set

before a tool path can be displayed.

Graphics display procedure

Set the drawing coordinates with parameter No.6510 before starting

drawing. See “Drawing Coordinate System” for the settings and

corresponding coordinates.

1 Press function key

CUSTOM

GRAPH

The graphic parameter screen shown below appears. (If this screen

does not appear, press soft key

[G.PRM].)

GRAPHIC PARAMETER O0001 N00020

WORK LENGTH W= 130000

WORK DIAMETER D= 130000

PROGRAM STOP N= 0

AUTO ERASE A= 1

LIMIT L= 0

GRAPHIC CENTER X= 61655

Z= 90711

SCALE S= 32

GRAPHIC MODE M= 0

S 0 T0000

MEM STRT **** FIN 12:12:24

[ G.PRM ][ ][ GRAPH ][ ZOOM ][ (OPRT) ]

2 Move the cursor with the cursor keys to a parameter to set.

3 Enter data, then press the

INPUT

key.

4 Repeat steps 3 and 4 until all required parameters are specified.

5 Press soft key

[GRAPH].

12.1

GRAPHICS DISPLAY

Procedure
