MAINTENANCE

B–64114EN/01

1. METHOD OF REPLACING BATTERY

743

METHOD OF REPLACING BATTERY

In a system using this CNC, batteries are used as follows:

Use

Component connected to

battery

Memory backup in the CNC control unit CNC control unit

Preservation of the current position indicated

by the separate absolute pulse coder

Separate detector interface

unit

Preservation of the current position indicated

by the absolute pulse coder built into the motor

Servo amplifier

Used batteries must be discarded according to appropriate local

ordinances or rules. When discarding batteries, insulate them by using

tape and so forth to prevent the battery terminals from short–circuiting.
