B–63002EN/01

12. PROGRAM CONFIGURATION

NC FUNCTION

121

The following table shows the basic addresses and the range of values to

be specified. The range, however, is that of CNC. Note that the range of

the machine is different from this.

Function Address Metric input Inch input

Program number O

(

1–9999 1–9999

Sequence number N 1–99999 1–99999

Preparatory function G 0–99 0–99

Dimension

word Setting

IS–B

X, Y, Z, Q,

R, I, J, K,

ABCU

±99999.999mm

±99999.999deg

±9999.9999inch (Note2)

±99999.999deg

word

Setting

unit

IS–C

,,,,

A, B, C, U,

V, W

±99999.9999mm

±99999.9999deg

±999.99999inch (Note2)

±9999.9999deg

Feed per min-

ute Setting

IS–B

1–240000mm/min 0.01–9600.00inch/min

ute

Setting

unit

IS–C

1–100000mm/min 0.01–4000.00inch/min

Feed per rotation,

Setting unit

F 0.01–500.00mm/rev 0.0001–9.9999inch/rev

Spindle function S 0–20000 0–20000

Tool function T 0–99999999 0–99999999

Miscellaneous func-

M 0–99999999 0–99999999

tion

B 0–99999999 0–99999999

Dwell, Setting

IS–B

0–99999.999

(sec or rev)

0–99999.999

(sec or rev)

unit

IS–C

0–9999.9999

(sec or rev)

0–9999.9999

(sec or rev)

Program number

specification

P 1–9999 1–9999

Number of repeats P 1–999 1–999

Offset number H, D 0–400 0–400

12.8

BASIC ADDRESSES

AND COMMAND

VALUE RANGE

 Basic Addresses and

Range of Values to Be

Specified (M series)
