A. RANGE OF COMMAND VALUE
APPENDIX
401
Increment system
IS–A IS–B IS–C
Least input increment 0.01 mm 0.001 mm 0.0001 mm
Least command
increment
0.01 mm 0.001 mm 0.0001 mm
Max. programmable
dimension
±999999.99 mm ±99999.999 mm ±9999.9999 mm
Max. rapid traverse *1 240000 mm/min 240000 mm/min 100000 mm/min
Feedrate range *1 1 to 240000
mm/min
1 to 240000
mm/min
1 to 100000
mm/min
Incremental feed 0.01, 0.1, 1, 10
mm/step
0.001, 0.01, 0.1,
1mm/step
0.0001, 0.001,
0.01, 0.1 mm/
step
Tool compensation 0 to ±999.99
mm
0 to ±999.999
mm
0 to ±999.9999
mm
Dwell time 0 to 99999.999
sec
0 to 99999.999
sec
0 to 99999.999
sec
Increment system
IS–A IS–B IS–C
Least input increment 0.001 inch 0.0001 inch 0.00001 inch
Least command
increment
0.01 inch 0.0001 inch 0.00001 inch
Max. programmable
dimension
±99999.999
inch
±9999.9999
inch
±393.70078
inch
Max. rapid traverse *1 240000 mm/min 240000 mm/min 100000 mm/min
Feedrate range *1 0.01 to 9600
inch/min
0.01 to 9600
inch/min
0.01 to 4000
inch/min
Incremental feed 0.001, 0.01, 0.1,
1 inch/step
0.0001, 0.001,
0.01, 0.1
inch/step
0.00001,
0.0001, 0.001,
0.01 inch/step
Tool compensation 0 to ±99.999
inch
0 to ±99.9999
inch
0 to ±99.9999
inch
Dwell time 0 to 99999.999
sec
0 to 99999.999
sec
0 to 9999.9999
sec
A.2
M SERIES
Linear axis
In case of metric input,
feed screw is metric
In case of inch input,
feed screw is metric
Previous page
Next page
