FANUC Series 16i/18i/21i/20i/160i/180i/210i-

MODEL A DESCRIPTIONS

Concerning the addition of

Optimum Torque acceleration/deceleration

B-63002EN/02-2

01 01.09.06 Newl

istered

FANUC Series 16

/18

/21

/20

/160

/180

/210

-MODEL A DESCRIPTIONS

Concerning the addition of Optimum Torque acceleration/deceleration

1.Type of applied technical documents

Name

FANUC Series 16

/18

/21

/20

/160

/180

/210

-MODEL A

DESCRIPTIONS

Spec.No./Ed. B-63002EN/02

2.Summary of Change

Group Name/Outline

New, Add,

Correct,

Delete

Applicable

Date

Basic

Optional

Function

Optimum Torque acceleration/deceleration

(M Series)

After 20.9 LOOK-AHEAD BELL-SHAPED

ACCELARATION/DECELERATION BEFORE

INTERPOLATION TIME CONSTANT CHANGE

FUNCTION (M Series),

the following item is added.

20.10 OPTIMUM TORQUE

ACCELERATION/DECELERATION (M Series)

Add Immediately

Unit

Maintenance

Parts

Notice

AI high precision contour control or AI nano high precision contour control

is needed for this function

Correction

Another

This function is available in the following software.

FS16i–MA : B0F4/02 or later

FS18i–MA : BDF4/02 or later

RISC software for AI High precision contouring control: B451/10 or later
